Deck
A 40-foot cockpit
Beam carried to the bow. Room for a team that still wants to stand.
Factory current · official GCC desk
World Cat 400CC-X specifications.
July 2026 factory sheet. Centre console on the same 39′8″ VectorFlo hull as the Island DC. Quad packages sit on that PDF even though the header still prints 1,200 hp.
39′8″LOA · 12′8″ beam
1,200hpheader rating · quads on the same sheet
604galfuel · up to 712
21″hull draft
| Specifications · 400CC-X · July 2026 sheet | |
|---|---|
| Length overall | 39′8″ (12.09 m) |
| Beam | 12′8″ (3.86 m) bow to stern |
| Hull draft | 21″ (0.53 m) |
| Bridge clearance | 9′0″ (2.74 m) |
| Dry weight with power, approx. | 14,500 lbs (6,577 kg) |
| Maximum horsepower, sheet header | 1,200 hp |
| Engine packages on the same PDF | Twin Yamaha 450 · quad Yamaha 350 · twin Mercury 425 V10 · twin Mercury 600 V12 · quad Mercury 425 V10 |
| Fuel | 604 gal (2,287 L) · up to 712 gal extended-range option |
| Typical cruise / WOT* | 27.5 mph · 1.13 mpg / 57.4 mph (*typical options, Yamaha 300s on the sheet footnote) |
worldcat.com/models currently lists the 400CC-X at 1,700 hp. Confirm power on the current Tarboro sheet. 400CC-X spec PDF
On the hull · factory highlights
- VectorFlo twin hull · 12′8″ beam carried bow to stern
- Triple captain’s chairs · seating for up to 20 with optional layouts
- 604 gallons in two under-deck aluminium tanks
- Portside Hooker sea-chest with acrylic top
- Transom door · fresh and salt washdown
- Three forward hatches: storage, anchor roller, windlass
Joystick, tower and Seakeeper stay on the Dubai order.
Helm
Triple chairs
Power is written on the sheet. Twin 600s or quads — not guessed.
Run
Gulf and ocean
604 gallons. 21 inches of draft. Specified in Dubai.
